Air Blown Fiber Optic Cable

Features

Installation：Duct, air blowing
Applications：FTTX, LAN communication
Standards：IEC60794-5; YD/T 1460.4; GB/T 7424.5
Temperature Range：Installation：-5℃~+45℃；In use：-20℃~+70℃

Cable Structure and Technical Parameter：

1. Fiber: tight buffer fibers
2. Strength Member:FRP
3. Outer Jacket: Flame resistant PVC or LSZH

Technical Parameter

CableType	GCYFTY－XB1.3(Meter+Cablediameter)
	2.0±0.1mm	2.3±0.1mm	2.5±0.1mm	2.8±0.1mm
Fiber Count	2～4	6～12	2～12	14～24
Thickness of HDPE sheath	Nominal value:0.20mm, Average value:0.15mm
Nominal Overall Diameter	2.0±0.1mm	2.3±0.1mm	2.5±0.1mm	2.8±0.1mm
Weight	4.0 kg/km	5.0 kg/km	6.0 kg/km	7.0kg/km
Cable Fiber Attenuation (single mode)	0.35dB/km max @1310nm 0.22dB/km max @1550nm
Max. Tensile Strength	40N	50N	60N	60N
Max. Crushing force	600N/100mm
Min. Bending radius -Static / Dynamic	10 / 20 outer Φ
Temperature	Storage -30～＋50℃；Installation-10～＋40℃；Operation-20～＋50℃
Cable service life (estimate value)	25 years

Fiber optical Characteristic (after cable)

Fiber type	Attenuation				Bandwidth	Effective modal bandwidth	10 Gb/s Link Length
Conditions	1310/1550nm		850/1300nm		850/	850nm	850nm
Conditions	Typical	Maximum	Typical	Maximum	1300nm	850nm	850nm
Unit	dB/km	dB/km	dB/km	dB/km	MHz.km	MHz.km	m
G652D	0.5/0.4	0.6/0.5	/	/	/	/	/
G657A1	0.5/0.4	0.6/0.5	/	/	/	/	/
G657A2	0.4/0.3	0.5/0.4	/	/	/	/	/
G657B3	0.5/0.4	0.6/0.5	/	/	/	/	/
62.5/125	/	/	3.5/1.0	3.5/1.5	≥160/500	/	/
50/125/	/	/	3.0/1.0	3.5/1.5	≥200/500	/	/
OM1	/	/	3.0/1.0	3.5/1.5	≥200/500	/	/
50/125/	/	/	3.0/1.0	3.5/1.5	≥500/500	/	/
OM2	/	/	3.0/1.0	3.5/1.5	≥500/500	/	/
OM3-150	/	/	3.0/1.0	3.5/1.5	≥700/500	≥950	150
OM3-300	/	/	2.5/0.8	3.0/1.0	≥1500/500	≥2000	300
OM4-550	/	/	2.5/0.8	3.0/1.0	≥3500/500	≥4700	550

Package
